Repair Of Common Problems Of Plastic Edge Banding Machine

Pulished on Sep. 07, 2018

1. Problems in the press part in Plastic Edge Banding Machine.

If the plate pressure is not tight, or the front and rear of the press plate are high and low, when the plate travels to the glued part, the rubber plate and the pinch wheel exert a certain pressure on the side of the plate, causing the plate to be displaced and deviate from the reference line, resulting in Subsequent processes cannot be completed.


The plate is pressed tightly, and the front and rear tightness are the same. Then the reference ruler and the contour wheel of the trimming tool are placed on the plate, and finally the tool is adjusted until the desired effect, and the problem is solved.

2. The trimming reference plane of PVC edge banding Machine did not find the board surface.

The trimming knife can accurately trim the edge of the edge banding thanks to the horizontal ruler (reverse wheel or arc plate) and the vertical ruler (profiling wheel) next to the trimming knife. If they don't fit snugly on the moving sheet, they will not be able to make the right lines.


Feed a long, flat-faced sheet into the edge banding machine (be careful not to apply glue). When the sheet travels to cover the position of polishing, scraping, finishing, roughing, stop the conveyor belt to the surface. For the reference, place the horizontal and vertical reference parts mentioned above on the board, and place the cutting edge of the tool close to the edge of the board, waiting for the fine adjustment later, until the desired effect appears.

3. The looseness of the screw causes the trimming to be unstable.

Solution: Find the datum, tighten the screws, and adjust the tool.

Plastic Edge Banding Machine
